The Litus 5 series features a sophisticated flush/trimless mount design. With a wide selection of optic options these fixtures are highly versatile for both general and more dynamic lighting. The square version can be used for downlight applications as well. The Bright 3, Smoothy 5 and Litus 5 series all use the same LED.
Application | In-grade Uplight |
Construction |
Body: Aluminum Alloy EN AW 6082 Lens: Tempered, serigraphed-gray, and transparent extra-clear glass |
Wattage | 3.5W, 5W, 7W, 7W RGB |
Power Supply | Remote 24VDC Constant VoltageRemote 700mA Constant Current (RGB) |
Dimming | Available, See Datasheet |
CCT | 2700K, 3000K, 4000K, RGB |
CRI | >80, >90 |
Delivered Lumens |
463 lm (3000K, 7W, 34°, CRI 80) 374 lm(3000K, 7W, 34°, CRI 90) RGB: 235 lm: (R) 92 lm, (G) 105 lm, (B) 38 lm (See Datasheet for more) |
Optic Options | 9 Standard (white), 4 Standard (RGB) |
Finishes | Glass |
Accessories | See Datasheet |
Bug Rating | B0-U3-G0 (3000K, all versions) |
Ingress Protection | IP67 |
Impact Resistance | IK08 |
Fixture equipped with IPS protection system and PID (Protective Impedance Device).
