The Ginko 3 series IP66, IP69 (suitable for power washing) projectors are adjustable through 360° using the magnet accessory. Available in a variety of finishes, optics (some models have integral adjustable optics), and 80 or 90 CRI. Ginko 3.0 is the Ø3.3” IP69 static white version. Narrow Beam Down to 2°
Ginko 3.0 was chosen out of 6400 candidate products from 50 countries around the world to win the prestigious international accolade iF Design Award 2019.
| Application | Floodlight/Projector |
| Construction |
Body: Anti-corrosive aluminum or 316L SS Bracket: Stainless Steel Lens: Tempered extra-clear glass |
| Wattage | 3W / 10W / 15W |
| Power Supply | Remote 24VDC Constant Voltage |
| Dimming | Available, See Datasheet |
| CCT | 2200K, 2700K, 3000K, 4000K |
| CRI | >80, >90 |
| Delivered Lumens | 609 lm - 1162 lm, See Datasheet |
| Optic Options | 2° (only available with 3W version), 8°, 13°, 30°, 42°, 48° Sharp, 58°, 12°x64°, 28°x72° |
| Finishes | 7 Standard, Custom RAL |
| Accessories | See Datasheet |
| Bug Rating |
B1-U0-G0 (3000K, 10W, 30°, 48°, 12°x64°) B1-U0-G0 (3000K, 15W, 48°) B1-U1-G0 (3000K, 10W, 13°, 42°, 58°, 28°x72°) B1-U1-G0 (3000K, 15W, 13°, 30°, 42°, 58°, 12°x64°, 28°x72°) |
| Ingress Protection | IP66, IP69 (Tested to EN / IEC 60598-1) |
| Impact Resistance | IK07 |
The entire Ginko family has won a Muuuz International Award (MIAW) for 2019.
