Ginko 1.0 LED, Ø1.3", 2.5W/3.5W, 124 lm - 193 lm 24VDC, IP66, IP69

The Ginko series IP66, IP69 (suitable for power washing) projectors are small and versatile. Available in a variety of finishes, optics (some models have integral adjustable optics), and 80 or 90 CRI. Ginko 1.0 is the Ø1.3″ static white version.

Application Floodlight/Projector
Construction Body: Anti-corrosive aluminum or 316L SS
Bracket: Stainless Steel
Lens: Tempered extra-clear glass
Wattage 2.5W / 3.5W
Power Supply Remote 24VDC Constant Voltage
Dimming Available, See Datasheet
CCT 2700K, 3000K, 4000K
(3500K on request, consult factory)
CRI >80, >90
Delivered Lumens 124 lm - 193 lm, See Datasheet
Optic Options 12° (4000K, CRI80 only), 19°, 36°,
38° Sharp, 58°, 16°x36°, 36°x16°
Finishes 7 Standard Finishes, See Datasheet
Accessories See Datasheet
Ingress Protection IP66, IP69 (Tested to EN / IEC 60598-1)
Impact Resistance IK07

Fixture comes equipped with IPS protection system.
The entire Ginko family has won a Muuuz International Award (MIAW) for 2019.

Available Quantity
(1) GN100105M5
