The Ginko 3 series IP66, IP69K (suitable for power washing) projectors are adjustable through 360° using the magnet accessory. Available in a variety of finishes, optics (some models have integral adjustable optics), and 80 or 90 CRI. Ginko 3.0 is the Ø3.3” IP69 static white version.
Ginko 3.0 was chosen out of 6400 candidate products from 50 countries around the world to win the prestigious international accolade iF Design Award 2019.
| Application | Floodlight/Projector |
| Construction |
Body: Anti-corrosive aluminum or 316L SS Bracket: Stainless Steel Lens: Tempered extra-clear glass |
| Wattage | 10W / 15W |
| Power Supply | Remote 24VDC Constant Voltage |
| Dimming | Available, See Datasheet |
| CCT | 2700K, 3000K, 4000K |
| CRI | >80, >90 |
| Delivered Lumens | 609 lm - 1162 lm, See Datasheet |
| Optic Options | 8°, 13°, 30°, 42°, 48° Sharp, 58°, 12°x64°, 28°x72° |
| Finishes | 7 Standard Finishes, See Datasheet |
| Accessories | See Datasheet |
| Bug Rating |
B1-U0-G0 (3000K, 10W, 30°, 48°, 12°x64°) B1-U0-G0 (3000K, 15W, 48°) B1-U1-G0 (3000K, 10W, 13°, 42°, 58°, 28°x72°) B1-U1-G0 (3000K, 15W, 13°, 30°, 42°, 58°, 12°x64°, 28°x72°) |
| Ingress Protection | IP66, IP69 (Tested to EN / IEC 60598-1) |
| Impact Resistance | IK07 |
Fixture comes equipped with IPS protection system.
The entire Ginko family has won a Muuuz International Award (MIAW) for 2019.
